Boot strap=00000a54 board_type=00000002
Uboot is running in (Mt Augusta)
DRAM: 2 GiB
WARNING: Caches not enabled
I2C :Ready
cpld: val=00
NAND: cs 0 dev_id word 0 2c380026
Micron MT29F8G08ABABA, blocks per lun: 800 lun count: 1
dumping inand[cs=0] addr[DFE80008]

ONFI info: device 1024MB, page 4096B, oobsize 224B, block 512KB,
col-addr 2, row-addr 3, 8-bit
Found strap type 0x2 strap page 0x2
REG_ACC_CONTROL c1040010 spare_area_bytes 10 ecc_level 4 eccbytes 7 steps 8
REG_CONFIG 48252300
512 KiB blocks, 4 KiB pages, 16B OOB, 8-bit
NAND: user oob per page: 3757153230 bytes (8 steps)
NAND: chipsize 1024 MiB
In: serial
Out: serial
Err: serial
arm_clk=1000MHz, axi_clk=499MHz, apb_clk=124MHz, arm_periph_clk=500MHz
Net: Registering eth
et0: phyaddr(0x1) id2(0xf) bcmiproc_eth-0
Hit Esc key to interrupt autoboot: 0
Booting PRIMARY configuration…

boot device : flash
file name : systema (FTOS system://A Partition)
Erasing Nand…
Erasing at 0x100000 — 100% complete.
Writing to Nand… done
Booting FTOS image
off 0x2700000 addr 0x6fffff10 siz c5a5d0
## Booting kernel from Legacy Image at 70000000 …
Image Name: netbsd
Created: 1970-01-01 0:00:00 UTC
Image Type: ARM NetBSD Kernel Image (gzip compressed)
Data Size: 12952720 Bytes
Load Address: 00100000
Entry Point: 00100000
Verifying Checksum … OK
Uncompressing Kernel Image … OK
## Transferring control to NetBSD stage-2 loader (at address 00100000) …
@ABC1234DEFG1HIJLYZ!
uboot arg = 0xdfe7ffe0, 0, 0xdff8d36c, 0xdff8d36c

NetBSD/evbarm (bcm53xx) booting …
initarm: Configuring system, CLIDR=1110000003 CTR=0x83338003 PMUSERSR=0
Loaded initial symtab at 0x815e8db0, strtab at 0x816cb378, # entries 57858
pmap_postinit: Allocated 35 static L1 descriptor tables
Copyright (c) 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005,
2006, 2007, 2008, 2009, 2010
The NetBSD Foundation, Inc. All rights reserved.
Copyright (c) 1982, 1986, 1989, 1991, 1993
The Regents of the University of California. All rights reserved.

Dell Networking OS Release 9.10(0.0)
NetBSD 5.1_STABLE (S3100) #0: Sun Apr 10 07:52:32 PDT 2016
total memory = 16383 PB
avail memory = 1937 MB
mainbus0 (root)
cpu0 at mainbus0 core 0: 1 GHz Cortex-A9 r4p0 (Cortex V7A core)
cpu0: DC enabled IC enabled WB disabled EABT branch prediction enabled
cpu0: 32KB/32B 4-way L1 Instruction cache
cpu0: 32KB/32B 4-way write-back-locking-C L1 Data cache
cpu0: 512KB/32B 16-way write-back-locking-D L2 Unified cache
iprockbde0 at mainbus0 IPROC dev_rev_id=0x1b342,Dev=b342,rev=0001

Created a iProc BCM switch device BA=0x48000000 IRQ=194 device=0xb342
BCM Bus Space mem Handle = 0x8363b3dc
_dma_pbase = 0x68000000
kva=0xcf000000/0x2000000,map=0xc24d0320,nsegs=1,pa=68000000/2000000
DMA VBASE:0xcf000000 DMA PBASE:68000000
armperiph0 at mainbus0
arml2cc0 at armperiph0: ARM PL310 r3p2 L2 Cache Controller (disabled)
arml2cc0: cache enabled
armgic0 at armperiph0: Generic Interrupt Controller, 256 sources (245 valid)
armgic0: 32 Priorities, 224 SPIs, 5 PPIs, 16 SGIs
a9tmr0 at armperiph0: A9 Global 64-bit Timer (500 MHz)
a9tmr0: interrupting on irq 27
bcmcca0 at mainbus0: BCM56340 (Rev A0)
bcmcca0: interrupting at irq 123
com0 at bcmcca0 channel 0: ns16550a, working fifo
com0: console
com1 at bcmcca0 channel 1: ns16550a, working fifo
bcmgpio0 at bcmcca0 gpio addr:0xff000060
gpio0 at bcmgpio0: 32 pins
bcmccb0 at mainbus0
bcmmdio0 at bcmccb0: MDIO bus @ 2 MHz
bcmrng0 at bcmccb0: Random Number Generator (512 bit FIFO)
bcmi2c0 at bcmccb0 port 1
iic0 at bcmi2c0: I2C bus
i2cctl0 at iic0
tmp75x0 at iic0 addr 0x49
tmp75x1 at iic0 addr 0x4a
stmrtc0 at iic0 addr 0x68
cpldx0 at iic0 addr 0x28 CPLD attched at 28
sfpx0 at iic0 addr 0x50 : SFP eeprom at addr 0x50
sfpx1 at iic0 addr 0x51 : SFP eeprom at addr 0x51
I2C SMBus initialization done
bcmi2c1 at bcmccb0 port 2
iic1 at bcmi2c1: I2C bus
i2cctl1 at iic1
s2eeprom0 at iic1 addr 0x50 : AT24Cxx compatible EEPROM
s2eeprom1 at iic1 addr 0x51 : AT24Cxx compatible EEPROM
s2eeprom2 at iic1 addr 0x52 : AT24Cxx compatible EEPROM
s2eeprom3 at iic1 addr 0x52 : AT24Cxx compatible EEPROM
psufanctlx0 at iic1 addr 0x58 – PSU FAN controller (MB) 0
psufanctlx1 at iic1 addr 0x58 – PSU FAN controller (MB) 1
max6639x0 at iic1 addr 0x2c Fan controller attached at 0x2c
WRITE SUCCESS[r-0x4]:0x10 – 0
curmon0 at iic1 addr 0x40 Current moniter attached at 0x40I2C SMBus initializati
on done
bcmeth0 at bcmccb0 port 0: Gigabit Ethernet Controller
bcmeth0: interrupting on irq 234
bcmeth0: Ethernet address 00:01:02:03:04:05
brgphy0 at bcmeth0 phy 1: BCM54616S 1000BASE-T media interface, rev. 2
brgphy0: 10baseT, 10baseT-FDX, 100baseTX, 100baseTX-FDX, 1000baseT, 1000baseT-FD
X, auto
bcmeth1 at bcmccb0 port 1: Gigabit Ethernet Controller
bcmeth1: interrupting on irq 235
bcmeth1: Ethernet address 00:01:02:03:04:07
OUI 0x001be9 model 0x0011 rev 2 at bcmeth1 phy 1 not configured
bcmnand0 at bcmccb0: nand revision 0x80000601
onfinand0 at bcmnand0: ONFI NAND Flash
onfinand_read_parameter_page:565 crc 0x510f integrity 0X510F
onfinand0: vendor: MICRON, model: MT29F8G08ABABAWP
onfinand0: page size: 4096 bytes, spare size: 224 bytes, block size: 524288 byte
s
onfinand0: LUN size: 2048 blocks, LUNs: 1, total storage size: 1024 MB
1G nand is present
onfinand0: column cycles: 2, row cycles: 3, width: x8
Found BBT table for chip
flash0 at onfinand0: NAND flash partition size 1024 KB, offset 0, read only
flash0: erase size 512 KB, page size 4096 bytes, write size 4096 bytes
flash1 at onfinand0: NAND flash partition size 512 KB, offset 0x100000
flash1: erase size 512 KB, page size 4096 bytes, write size 4096 bytes
flash2 at onfinand0: NAND flash partition size 256 KB, offset 0x180000, read onl
y
flash2: erase size 512 KB, page size 4096 bytes, write size 4096 bytes
flash3 at onfinand0: NAND flash partition size 256 KB, offset 0x1c0000, read onl
y
flash3: erase size 512 KB, page size 4096 bytes, write size 4096 bytes
flash4 at onfinand0: NAND flash partition size 512 KB, offset 0x200000, read onl
y
flash4: erase size 512 KB, page size 4096 bytes, write size 4096 bytes
flash7 at onfinand0: NAND flash partition size 28 MB, offset 0x400000, read only

flash7: erase size 512 KB, page size 4096 bytes, write size 4096 bytes
flash8 at onfinand0: NAND flash partition size 1024 KB, offset 0x2000000
flash8: erase size 512 KB, page size 4096 bytes, write size 4096 bytes
flash9 at onfinand0: NAND flash partition size 1024 KB, offset 0x2100000
flash9: erase size 512 KB, page size 4096 bytes, write size 4096 bytes
flash10 at onfinand0: NAND flash partition size 1024 KB, offset 0x2200000
flash10: erase size 512 KB, page size 4096 bytes, write size 4096 bytes
flash11 at onfinand0: NAND flash partition size 2048 KB, offset 0x2300000
flash11: erase size 512 KB, page size 4096 bytes, write size 4096 bytes
flash12 at onfinand0: NAND flash partition size 2048 KB, offset 0x2500000, read
only
flash12: erase size 512 KB, page size 4096 bytes, write size 4096 bytes
flash13 at onfinand0: NAND flash partition size 128 MB, offset 0x2700000
flash13: erase size 512 KB, page size 4096 bytes, write size 4096 bytes
flash14 at onfinand0: NAND flash partition size 128 MB, offset 0xa700000
flash14: erase size 512 KB, page size 4096 bytes, write size 4096 bytes
flash15 at onfinand0: NAND flash partition size 728 MB, offset 0x12700000
flash15: erase size 512 KB, page size 4096 bytes, write size 4096 bytes
ld0 at flash15 child attached
bcmusb0 at bcmccb0
ohci0 at bcmusb0: OHCI USB controller
ohci0: OHCI version 1.0, legacy support
usb0 at ohci0: USB revision 1.0
ehci0 at bcmusb0: ECHI USB controller
ehci0: companion controller, 2 ports each: ohci0
usb1 at ehci0: USB revision 2.0
bcmusb0: interrupting on irq 117
ld0: 728 MB, 740 cyl, 32 head, 63 sec, 512 bytes/sect x 1492991 sectors
ld0: sector size : 512, number of sectors : 1492991uhub0 at usb0: Broadcom OHCI
root hub, class 9/0, rev 1.00/1.00, addr 1
uhub1 at usb1: Broadcom EHCI root hub, class 9/0, rev 2.00/1.00, addr 1
netdisk:netdisk attach invoked..
Too many symbols for tree, skipping 25091 symbols
f10mc pseudo-device
platform pseudo-device
WRITE SUCCESS[r-0x4]:0x10 – 0x10
max6639: smbus timeout enabled
crshntfy pseudo-device
bshell pseudo-device
s3100_diag as pseudo-device getting attached
Broadcom Device Enumerator (nbsd_ubde)
0: Interrupt mode CMICm
bcnp pseudo-device
bcmw pseudo-device
bcmwstk pseudo-device
bcmws pseudo-device
f10logger as pseudo-device getting attached
bfd pseudo-device
boot device:
root on md0a dumps on netdisk0a
WARNING: clock gained 3243 days
WARNING: CHECK AND RESET THE DATE!
route: writing to routing socket: File exists
add host 0.0.0.0: gateway 127.0.0.1: File exists
0x815cff34

0x815cff34

Size of ReleaseImage is 48182049 Bytes

RELEASE IMAGE HEADER DATA :
————————–
Release Image SW Image Count : 4
Release Image Major-Version : 9
Release Image Minor Version : 10
Release Image Maint Version : 0
Release Image Patch-Version : 0
Release Image Header Size : 140
Release Image Data Size : 48181909
Release Image Platform Type : 27
Release Image Product Name : FTOS-S3100
Release Image Checksum Value : 0x2249a978
Release Image Header Checksum: 0xa94a0168
Release Image Create Year : 2016
Release Image Create Month : 4
Release Image Create Date : 10
Release Image Create Hour : 7
Release Image Create Minute : 54
Release Image Create Second : 7

SOFTWARE IMAGE HEADER DATA :
—————————-
Software Image[1] Major Version : 9
Software Image[1] Minor Version : 10
Software Image[1] Maint Version : 0
Software Image[1] Patch Version : 0
Software Image[1] Image type : 2
Software Image[1] Header Size : 100
Software Image[1] Img Data Size : 12952800
Software Image[1] Img Orig Size : 12952800
Software Image[1] Family Code : cp
Software Image[1] Img file Name : CPRPLP-RPM-AP-9.10.0.0.bin
Software Image[1] Hdr Checksum : 0xa93a510
Software Image[1] Data Checksum : 0x8065145d

SOFTWARE IMAGE HEADER DATA :
—————————-
Software Image[2] Major Version : 9
Software Image[2] Minor Version : 10
Software Image[2] Maint Version : 0
Software Image[2] Patch Version : 0
Software Image[2] Image type : 2
Software Image[2] Header Size : 100
Software Image[2] Img Data Size : 25011656
Software Image[2] Img Orig Size : 66611216
Software Image[2] Family Code : nbsdpcprplp
Software Image[2] Img file Name : NBSDPCPRPLP-RPM-AP-9.10.0.0.bin
Software Image[2] Hdr Checksum : 0x9bdc5188
Software Image[2] Data Checksum : 0xc20af5e6

SOFTWARE IMAGE HEADER DATA :
—————————-
Software Image[3] Major Version : 9
Software Image[3] Minor Version : 10
Software Image[3] Maint Version : 0
Software Image[3] Patch Version : 0
Software Image[3] Image type : 2
Software Image[3] Header Size : 100
Software Image[3] Img Data Size : 9587357
Software Image[3] Img Orig Size : 24350736
Software Image[3] Family Code : nbsdlibcp
Software Image[3] Img file Name : NBSDLIBCP-RPM-AP-9.10.0.0.bin
Software Image[3] Hdr Checksum : 0x6eae1f58
Software Image[3] Data Checksum : 0x9e2eda42

SOFTWARE IMAGE HEADER DATA :
—————————-
Software Image[4] Major Version : 5
Software Image[4] Minor Version : 2
Software Image[4] Maint Version : 1
Software Image[4] Patch Version : 4
Software Image[4] Image type : 1
Software Image[4] Header Size : 100
Software Image[4] Img Data Size : 629696
Software Image[4] Img Orig Size : 629696
Software Image[4] Family Code : cp
Software Image[4] Img file Name : CPRPLP-RPM-BT-5.2.1.4.bin
Software Image[4] Hdr Checksum : 0x17bd35ed
Software Image[4] Data Checksum : 0x155c9fec
Partitioning 1G flash parition flash15…Pass!
Starting Dell Networking OS

Feb 25 15:47:27: %S3124:1 %POLLMGR-2-USER_FLASH_STATE: USB flash disk missing in
‘usbflash:’

……Feb 25 15:47:30: %STKUNIT1-M:CP %RAM-6-ELECTION_ROLE: Stack-unit 1 is tran
sitioning to Management Stack-unit.
….Feb 25 15:47:42: %STKUNIT1-M:CP %CRYPTO-5-FIPS_SELF_TEST_PASSED: [sysd] FIPS
crypto module self-test passed
Feb 25 15:47:42: %STKUNIT1-M:CP %CHMGR-5-STACKUNIT_DETECTED: stack-unit 1 presen
t
Feb 25 15:47:45: %STKUNIT1-M:CP %CHMGR-5-LPM_CONFIG: Applying the default IPv6 L
PM partition config
Feb 25 15:47:47: %STKUNIT1-M:CP %CHMGR-5-CHECKIN: Checkin from stack-unit 1 (typ
e S3124, 30 ports)
.Feb 25 15:47:50: %STKUNIT1-M:CP %CHMGR-5-STACKUNIT_UP: stack-unit 1 is up

f10coreSSNKernelCorePresent: 1318
Feb 25 15:48:19: %S3124:1 %CHMGR-5-FAN_SPEED_CHANGE: Fan speed changed to 55 % o
f the full speed
Feb 25 15:48:20: %STKUNIT1-M:CP %RAM-5-STACKUNIT_STATE: Stack-unit 1 is in Activ
e State.
Feb 25 15:48:20: %STKUNIT1-M:CP %CHMGR-2-SYSTEM_READY: System ready
Feb 25 15:48:32: %STKUNIT1-M:CP %CHMGR-5-PEM_INSERTED: Power entry module 1 of u
nit 1 is inserted
Feb 25 15:48:32: %STKUNIT1-M:CP %CHMGR-0-PS_UP: Power supply 1 in unit 1 is up
Feb 25 15:48:32: %STKUNIT1-M:CP %CHMGR-4-TEMP_STATUS_CHANGE: Unit 1 temperature
state changed to 0 (Current temperature 30C).
Feb 25 15:48:32: %STKUNIT1-M:CP %CHMGR-5-FANTRAY_INSERTED: Fan tray 1 of Unit 1
is inserted
Feb 25 15:48:32: %STKUNIT1-M:CP %CHMGR-5-PSU_FAN_STATUS: Fan 1 in PSU 1 of Unit
1 is up
Feb 25 15:48:36: %STKUNIT1-M:CP %SYS-5-CONFIG_LOAD: Loading configuration file
Feb 25 15:48:48: %STKUNIT1-M:CP %SUPPORT_ASSIST-3-SUPASSIST_PKG_INSTALLATION_ERR
OR: SupportAssist package installation encountered error : No Smartscripts Packa
ge found.
, exist status: 1

Feb 25 15:48:50: %STKUNIT1-M:CP %SUPPORT_ASSIST-6-SUPASSIST_PKG_UNINSTALLED: Sup
portAssist package uninstalled
Feb 25 15:48:50: %STKUNIT1-M:CP %BMP-5-BMP_POST_SCRIPT_NOT_PRESENT: The Post-Con
fig Script is not present.
Feb 25 15:48:51: %STKUNIT1-M:CP %SEC-5-LOGIN_SUCCESS: Login successful on consol
e
Dell>
Dell>en

The SupportAssist EULA acceptance option has not been selected. SupportAssist
can be enabled once the SupportAssist EULA has been accepted. Use the:
‘support-assist activate’ command to accept EULA and enable SupportAssist.

Dell#Feb 25 15:48:55: %STKUNIT1-M:CP %SEC-4-ENABLE_PASSW_NOT_CONFIGURED: Enable
password is required for authentication but not configured (by default from cons
ole)
Feb 25 15:48:55: %STKUNIT1-M:CP %SEC-5-AUTHENTICATION_ENABLE_SUCCESS: Enable aut
hentication success on console

Dell#show version
Dell Real Time Operating System Software
Dell Operating System Version: 2.0
Dell Application Software Version: 9.10(0.0)
Copyright (c) 1999-2016 by Dell Inc. All Rights Reserved.
Build Time: Sun Apr 10 06:42:55 2016
Build Path: /sites/eqx/work/swbuild01_1/build16/E9-10-0/SW/SRC
Dell Networking OS uptime is 2 minute(s)

System image file is “system://A”

System Type: S3124
Control Processor: Broadcom 56340 (ver A0) with 2 Gbytes (2147483648 bytes) of m
emory, core(s) 1.

1G bytes of boot flash memory.
